Description
Rancho RS5000X RS55143 Suspension Shock Absorber for Toyota PickupFeaturing a unique, exclusive valving system and advanced compression functionality, Rancho® RS5000™X shocks deliver improved overall on- and off-road handling and performance.
- IMPROVED HANDLING AND PERFORMANCE — Cross Tuned technology featuring exclusive rebound valving system and advanced compression phase improves overall handling and performance on and off road
- MINIMIZES ROUGH RIDE — Exclusive Progressive Engagement Valving is custom-tuned for each vehicle to help reduce initial impacts at low speeds and minimizes a rough ride
- STRONG AND DURABLE — Features a 16mm nitro-carburized piston rod to resist scuffs & corrosion, double-welded loops at stress areas, 35mm sintered iron piston for enhanced structural integrity and polyvinyl protective boot
- HANDLES EXTREME TEMPERATURE CHANGES — Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248°F
- SMOOTH PERFORMANCE — Polyurethane rebound bumper and rubber bushings help absorb ride harshness while the fluon-banded piston enhances responsiveness to changing road conditions for an overall smoother ride
- REDUCES FADE — Nitrogen gas pressurized to 150 PSI to minimize air-to-oil mixture to reduce damping performance fade and foaming
- MAINTAINS VEHICLE CONTROL — Compression Control Valve is custom-tuned for each vehicle to regulate fluid transfer to absorb impacts without disc flutter and help maintain shock motion control
- BUILT TO LAST — Low-friction, self-lubricating seal retains gas and oil for quicker rebound and smoother compression while the application-specific piston delivers heightened control of shock motion due to the expanded piston area
- BUY WITH CONFIDENCE — Comes with Rancho’s Limited Lifetime Warranty
Application Summary:
|
|
| Year |
Make/Model |
| 1968-1971 |
Dodge W100 Pickup |
| 1961-1967 |
Dodge W100 Series |
| 1968-1971 |
Dodge W200 Pickup |
| 1961-1967 |
Dodge W200 Series |
| 1984-1985 |
Toyota 4Runner |
| 1984-1985 |
Toyota Pickup |
|
|
| Attributes |
| Adjustable Damping |
No |
| Adjustable Rebound |
No |
| Air Adjustable |
No |
| Air Ride Suspension |
No |
| Bearing Plate Included |
No |
| Body Color |
White |
| Body Diameter |
2.251, 57.2 |
| Body Material |
Steel |
| Boot Included |
Yes |
| Coil Over Springs Included |
No |
| Collapsed Length |
15.560 in. |
| Color |
White |
| Country of Origin (Primary) |
US |
| Cylinder Color |
White |
| Cylinder Material |
Steel |
| Cylinder Outside Diameter |
2.251 |
| Dust Shield Color |
Red |
| Extended Length |
25.22, 640.6 |
| Finish |
Painted |
| Gas Charged |
Yes |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8708801600 |
| Hazardous Material Code |
N |
| Internal Construction Type |
Dual Tube, Twin Tube |
| Life Cycle Status Code |
Available to Order |
| Lower Mount Code |
L3 |
| Lower Mount Type |
Loop Bushing Mount – 3/4″ Bushing ID X 1.9/16″ Bushing OAL |
| Mounting Hardware Included |
No |
| NAFTA Preference Criterion Code |
B |
| New Or Remanufactured |
New |
| Part Description |
Shock Absorber |
| Parts Pack |
None |
| Product Grade |
Premium |
| Rod Diameter |
0.622 |
| SDR Required Flag |
Y |
| SDS Sheet Number |
01164 |
| Shaft Material |
Nitrocarburized |
| Shock Absorber Body End Measuring Point |
Center of Loop |
| Shock Absorber Bore Size |
1.3779527559055118 |
| Shock Absorber Rod End Measuring Point |
Center of Loop |
| Shock Stroke |
9.660 in., 9.66 |
| Spring Included |
No |
| Spring Isolators Included |
No |
| Spring Seat Included |
No |
| Total Part VIO |
21394 |
| Type |
Telescopic |
| Upper Mount Code |
L3 |
| Upper Mount Type |
Loop Bushing Mount – 3/4″ Bushing ID X 1.9/16″ Bushing OAL |
| GTIN |
00039703011426 |
